德国EH电磁流量计代理代理商销售 EH电磁流量计代理价格
E+H电磁流量计代理配备超紧凑型变送器的卫生行业应用专家
Promag H 传感器适用于食品与饮料、生命科学行业中对测量要求zui高的苛刻应用。超紧凑型变送器具备业界zui小的外壳，却能提供zui全面的性能，轻松实现无缝系统集成，因此，Promag H 100 成为了撬装设备制造商、系统集成商和其他设备制造商的*。
E+H电磁流量计代理优势
流量、温度、电导率的多变量测量
安装灵活-多种符合卫生要求的过程连接
节能型流量测量-横截面与管道*，无压损
节约空间的变送器-设备虽小，功能全面
无需增加硬件和软件即可提供本地化操作，节约时间-集成网络服务器
集成验证 - Heartbeat Technology
免维护 – 无可动部件
E+H电磁流量计代理应用领域
双向测量不受压力、密度、温度和粘度影响
适用于食品与饮料、生命科学行业的苛刻应用
设备特性
内置温度测量
传感器外壳采用不锈钢材质 (3-A, EHEDG)
接液部分材质耐 CIP, SIP 清洗
坚固的超紧凑型变送器外壳
高保护等级： IP69
带现场显示
Promag H100电磁流量计特征和规格
| 测量原理 | 电磁 |
| 主要特点 | The specialist for hygienic applications with an ultra‐compact transmitter. M*riable measurement for flow, temperature and conductivity. Dedicated to demanding applications in the food and beverage as well as in life sciences industries. |
| 特点 | Flexible installation concept – numerous hygienic process connections. Energy‐saving flow measurement – no pressure loss due to cross‐section constriction. Maintenance‐free – no moving parts. Integrated temperature measurement. Sensor housing made of stainless steel (3-A, EHEDG). |
| Transmitter features | Space‐saving transmitter – full functionality on the smallest footprint. Time‐saving local operation without additional software and hardware – integrated web server. Integrated verification – Heartbeat Technology. Robust, ultra‐compact transmitter housing. High ingress protection: IP69. |
| 直径 | DN 2 to 150 (¹⁄₁₂ to 6) |
| Wetted materials | Liner: PFA |
| Measured variables | Volume flow, temperature, conductivity, mass flow, corrected volume flow, corrected conductivity |
| 测量误差 | Volume flow (standard): ±0.5 % o.r. ± 1 mm/s (0.04 in/s) |
| 量程 | 0.06 dm³/min to 600 m³/h (0.015 to 2650 gal/min) |
| 压力范围 | PN 40, Class 150, 20K |
| 过程温度 | –20 to +150 °C (–4 to +302 °F) |
| 环境温度 | –40 to +60 °C (–40 to +140 °F) |
| Sensor housing material | 1.4301 (304), corrosion resistant |
| Transmitter housing material | Compact: AlSi10Mg, coated |
| 电子插件的防护 | Standard: IP66/67, type 4X enclosure |
| 显示/操作 | 4‐line backlit display available (no local operation) |
| 输出 | 4‐20 mA HART (active) |
| 输入 | None |
| 通信 | HART, PROFIBUS DP, Modbus RS485, EtherNet/IP, PROFINET |
| Power supply | DC 20 to 30 V |
| 防爆认证 | ATEX, IECEx, cCSAus, INMETRO, EAC |
| Product safety | CE, C-tick |
| Metrological approvals and certificates | Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025) Heartbeat Verification: Heartbeat Technology complies with requirements for traceable verification according to ISO 9001:2008, chapter 7.6. a (TUV attestation) |
